Produkte

ASLS Series
0.4mm pitch micro coaxial cable connector/stack connection type

The “ASLS Series” is a connector for 0.4 mm pitch micro coaxial cable (AWG#42).

Hauptmerkmale
- A compact connector with a mounting height of 1.65 mm and a mating width of 2.80 mm
- It is non-magnetic and not affected by magnetic fields
- W crimp structure enhances cable retention
- The contact uses a two-point contact structure that provides contact reliability
- By using a metal shell, noise prevention and product strength are ensured
- Multiple ground terminals are provided to improve transmission characteristics/EMS characteristics
TMC Series
0.5 mm pitch connector for micro coaxial cables/Compatible with high-speed differential transmission/Horizontal and vertical mating type

The TMC Series is a 0.5 mm pitch connector for micro coaxial cables that supports high-speed differential transmission with a lock mechanism that enables easy mating/removal. The connection methods are horizontal and vertical mating. The compatible cables are AWG#36/38/40.

Hauptmerkmale
- It is suitable for high-speed differential transmission (TMDS, LVDS)
- A metal shell is used to reduce noise and ensure product strength
- Multiple ground terminals are provided to improve the transmission and the EMS characteristics
- An effective mating length of 1.0 mm is secured
- Equipped with a lock mechanism that enables secure and easy mating and removal
- A straight type and a right angle type are available for the PCB side connector, so both horizontal mating and vertical mating are available
- Number of contacts: 51
TSL-NM2 Series
0.55mm pitch high performance coaxial harness/non-magnetic type

The TSL-NM2 series is a 0.55mm pitch high-performance coaxial harness that is non-magnetic and low profile in response to further market needs beyond the conventional TSL series that enables high-speed differential transmission of up to 32Gbps.
It is not affected by magnetic fields and has a mating height of 2.17mm (horizontal mating).
Suitable cables are AWG#30/32/36.

Hauptmerkmale
- It is compatible with high-speed differential transmission up to 32 Gbps
- In addition to achieving impedance control by adjusting the connector material, shape, and dimensions, the amount of attenuation has been improved by taking anti-resonance measures through the grounding method and by smoothing the transmission paths
- With the effective mating length, which affects contact reliability set at 0.5 mm, the attenuation amount has been improved by reducing the insert sink and optimizing the design of the stub length in relation to the transmission characteristics
- Noise reduction is further enhanced by the multiple ground mechanism and the structure that encloses the entire connector inside a metal shell cover
- By combining it with TOTOKU Corporation’s high-performance coaxial cable “RUOTA,” low loss and low skew are achieved
- It is non-magnetic and not affected by magnetic fields
- Features a locking structure that provides audible “click”
XSL Series
0.25 mm pitch connector for micro coaxial cables/Horizontal mating type

The XSL Series is a 0.25 mm pitch compact connector for micro coaxial cables. It is the industry’s smallest connector, and it saves space in the occupied area on board. The compatible cables are AWG#44/46.

Hauptmerkmale
- Compact connector with a mounting height of 1.0 mm and a mating width of 6 mm
- The cable assembly uses a one-shot soldering method with signal line pulse heat, achieving a stable and highly reliable connection
- A metal shell is used to reduce noise and ensure product strength
- Multiple ground terminals are provided to improve the transmission and the EMS characteristics
- An effective mating length of 0.51 mm is secured
- Number of contacts: 48
XSLS-Serie
0,25 mm Raster, gestapelte Verbindung, ultrakompakt

Unsere XSLS-Serie ist der branchenweit kompakteste Steckverbinder mit einem Raster von 0,25 mm und stapelbarer Verbindung, was mehr Platz auf der Leiterplatte spart.

Hauptmerkmale
- Can absorb a mating error of ±3 mm in the X and Y directions
- Reliable design with an effective mating length of 3 mm
- Crimp contacts employ a twin-leaf pinching two-point contact structure
- FA12 connectors for relaying cables support hot swap
USLS-Serie
Gestapelte Verbindung mit niedrigem Profil

Bei unserer USLS-Serie handelt es sich um einen Mikro-Koaxialkabel-Steckverbinder mit gestapelter Verbindung und einem Raster von 0,4 mm.

Hauptmerkmale
- Kompakter Steckverbinder mit niedrigem Profil
- Einfaches Stecken
- Bleifrei durch Schneidklemmverbinder (IDC)
- Bauhöhe: 1,65 mm; Steckbreite: 3,05 mm
- Effektive Stecklänge: 0,35 mm
- Kabelquerschnitt: AWG 42
USL-Serie
0,4 mm Raster, Schneidklemmverbinder (IDC)

Die USL-Serie ist ein Steckverbinder mit einem Raster von 0,4 mm für Mikro-Koaxialkabel (AWG 42). Die Massenverbindung durch Pressschweißen verbessert die Verbindungszuverlässigkeit und macht den Steckverbinder kompakt.

Hauptmerkmale
- Verbesserte Verbindungszuverlässigkeit und kompakte Größe durch Massenverbindung mittels Pressschweißen
- Trägt zur Miniaturisierung von Geräten bei
- Bauöhe: 1,0 mm; Steckbreite: 5,6 mm
- Effektive Stecklänge: 0,5 mm
- Kabelquerschnitt: AWG 42
TSL-Serie
0.55 mm Pitch, 32 Gbps High-Speed Transmission Next-Generation Harness

Bei unserer TSL-Serie handelt es sich um einen Kabelbaum, der eine differenzielle Hochgeschwindigkeits-Datenübertragung von 32 Gbit/s bei einer Länge von 1.000 mm ermöglicht. Das Steckverbinderdesign ist für eine Hochgeschwindigkeits-Datenübertragung über lange Leitungen für 5G, IoT und KI optimiert.

Hauptmerkmale
- Geringer Verlust und geringe Laufzeitdifferenz in Kombination mit den neuen Hochleistungs-Koaxialkabeln von Ruota*
- Differenzielle Hochgeschwindigkeits-Datenübertragung von 32 Gbit/s bei einer Kabelbaumlänge von 1.000 mm
- Bauhöhe: 3,25 mm; Steckbreite: 10,68 mm (horizontale Verbindung)
- Effektive Stecklänge: 0,5 mm
- Kabelquerschnitt: AWG 30, 32, 36
SSL-Serie
0,5 mm Raster, Schneidklemmverbinder (IDC)

Bei unserer SSL-Serie handelt es sich um einen Mikro-Koaxialkabel-Steckverbinder mit einem Raster von 0,5 mm. Die Pressschweißverbindung gewährleistet höchste Zuverlässigkeit und Kompaktheit.

Hauptmerkmale
- Rechtwinklige und horizontale Verbindung verfügbar
- Metallgehäuse zur Geräuschreduzierung und Produktfestigkeit
- Bauhöhe: 1,4 mm; Steckbreite: 6,08 mm (horizontale Verbindung)
- Effektive Stecklänge: 0,5 mm
- Kabelquerschnitt: AWG 40
8900MS Series
1.27 mm pitch connector/Low-profile type

The 8900MS series is a 1.27mm pitch printed circuit board-to-printed circuit board connector for low profile profile SMT. It can also be mated with the DIP type of the 8900 series.

Hauptmerkmale
- Insulator structure that protects from three directions prevents contact deformation
- Surface contact enables low insertion/removal force and the highly reliable design secures contact force and trailing capability
- PPS is used for the insulator material to ensure heat resistance
- Equipped with a retention clip to reduce stress on the lead
8900 Series
1.27 mm pitch connector/Low-profile type

The 8900 Series is a 1.27 mm pitch, low-profile, board-to-board connector. The straight type has five variations of height ranging from 7 mm to 12 mm. It is also available with or without a metal hook.

Hauptmerkmale
- Insulator structure that protects from three directions prevents contact deformation
- Surface contact enables low insertion/removal force and the highly reliable design secures contact force and trailing capability
- Reliable mating is possible with a audible “click”
- Available in two types, with and without flanges
8832E-FS Series
1.27 mm pitch 2-piece connector/Flexible stack type

The 8903N-FS series is a 1.27mm pitch printed circuit board-to-printed circuit board connector with a choice of stack heights. It can be mated with the plug side of the 8900 series.

Hauptmerkmale
- Insulator structure that protects from three directions prevents contact deformation
- Surface contact enables low insertion/removal force and the highly reliable design secures contact force and trailing capability
- Reliable mating is possible with a audible “click”
- Mating partner can be selected from the 8913/8930E/8931E series
8806 / 8807 Series
1.27mm pitch connector/ multi pin type

The 8806/8807 series is a multi pin pin type 1.27mm pitch printed circuit board-to-printed circuit board connector offering straight/right angle configuration.

Hauptmerkmale
- Completely independent two-point contact maintains stable contact at all times
- Surface contact achieves a low insertion and withdrawal force, contributing to better contact durability
- Smooth mating is possible with the guide mechanism
- Connection method: Stacked/horizontal/vertical mating
8800 Series
1.27 mm pitch connector

The 8800 Series is a 1.27 mm pitch board-to-board connector. It is available in straight and right-angle types, with or without fixing clips, and also with power contacts.

Hauptmerkmale
- Completely independent two-point contact maintains stable contact at all times
- Surface contact achieves a low insertion and withdrawal force, contributing to better contact durability
- Plug and receptacle have same contact shapes, enabling significant cost reduction through shared use of molds and reduced material costs
- Connection method: Stacked/horizontal/vertical mating
GC / GD Series
5mm pitch/3mm pitch 1 piece battery connector

The GC/GD series is a connector for lithium-ion compatible batteries. It is used for connection when exchanging the IC signal of the battery pack of small devices such as PCs and handy terminals between the main unit and the battery pack.

Hauptmerkmale
- Stroke displacement quantity is ensured despite its compact design. (GC: 2.5mm, GD: 2.3mm)
- Contact structure with self-cleaning mechanism
- Highly reliable spring design that ensures contact stability
- Gold-gold-plated finish for improved contact reliability
GF series
2mm pitch 2 piece battery connector

The GF series is a 2mm pitch lithium polymer battery connector allowing a significant reduction in profile compared to conventional products.

Hauptmerkmale
- Low profile battery connector. (Mounting height 2.6mm: GF31 series)
- Guaranteed 5,000 mating/unmating life
- Corresponds to hot swap
- Connection method: horizontal mating, stacked mating
